E4 XANDY AX108 ROSY读出系统

金刚石探测器

市场价:￥0.00

价格:￥0.00

XANDY is the data acquisition system, power controller and monitoring unit for the Diamond XBPM® detector. It provides the measurement of the 4 quadrants, A, B, C, D of the XBPM® detector as well as the intensity and relative position of the X-ray beam in x and y at experimental beam lines of Synchrotron Light Sources. Results are transferred from the embedded Linux-based device server via Ethernet to the control system or to the desktop, where the browser-based GUI provides easy access to the data for on-line monitoring. Parameters: Type: XANDY AX108 Number of channels: 4 Embedded amplifiers: Switch amplifier Data rate: 1 - 10 - 100 kHz Data resolution: 24 bit Output: Output: A, B, C, D, x, y, I Data format: 32 bit Interface: Browser-based GUI API: Epics, Tango Communication rate: 1 Hz to control system I/O connections: A, B, C, D four analogue inputs with BNC connectorsExTrigg analogue input for external trigger DAC 1 & 2 analogue output for feedback to beam controlBias output for detector bias voltageLAN for remote connection2 USB socketsHDMI for monitor Power supply: Integrated power supply for XBPM® detector +50 V @ 1 mA 2 DAC output, 16 bit, ˘10 V Chassis: 19” Table top19” Rack mountInterfaces: Browser-based GUI for data acquisition and monitoringBrowser-based GUI for power controlAPI for communication to control systems1
超高温放大器

金刚石探测器

市场价:￥0.00

价格:￥0.00

The Cx-HT High-Temperature Amplifier is used at temperatures up to 180˝ C. It is made for nuclear fusion diagnostics in Tokamak environments and for geodetical applications. The Cx-HT High-Temperature Amplifier is a spectroscopic charge integrating amplifier with a semi-Gaussian signal shape. Features: Type: Spectroscopic amplifier for high temperatures Maximum operating temperature: 180˝C Gain: 2.9 mV/fC Input coupling: AC coupled (1 nF @ 1 kV) Polarity: Non-inverting, positive Power supplies: Supply voltage: +12 V @ 20 mA Bias-Tee: Integrated Maximum Bias voltage: ˘500 V
MNTB7-HT 金刚石快中子一体化探测器

金刚石探测器

市场价:￥0.00

价格:￥0.00

The MNTB7-HT Axial Instrumented Diamond Neutron Monitor integrates detector and spectroscopic amplifier in one solid stainless-steel housing. The Axial Detector can be operated up to 180° C. The sensing volume of the single-pad detector can be enlarged to 9 diamond sensors. FEATURESDetector type:Axial - Instrumented Diamond Neutron MonitorNumber of sensors:1 or 4 or 9 sCVD sensorsOutput signal:Semi-Gaussian with 250 ns FWHMSupply voltages:+12 V for amplifier, +50 V for sensor biasMaximum operating temperature:180° COPTIONSThe Axial Instrumented Neutron Monitor can be provided as self-standing monitoring system:<ul style="color: rgb(97, 92, 92); font-family: localFont1, "Times New Roman", Helvetica, Arial, sans-serif; font-size: 18px; white-space: normal;" class=" list-paddingleft-2"><li>Fast-Neutron Monitoring System including ROSY® AX106 with integrated power supply and Neutron Spectroscopy Application for real-time neutron monitoring.</li></ul>
塑料闪烁体

有机闪烁体

市场价:￥0.00

价格:￥0.00
液体闪烁体

有机闪烁体

市场价:￥65.00

价格:￥60.00
ALPHA/BETA DETECTION

有机闪烁体

市场价:￥0.00

价格:￥0.00
无机闪烁体

无机闪烁体

市场价:￥0.00

价格:￥0.00
A1金刚石束损监测器

CIVIDEC束线装置

市场价:￥0.00

价格:￥0.00

Machine Protection – Bunch-by-BunchThe A1 Diamond Beam Loss Monitor is used to measure beam losses at particle accelerators. It is designed for beam loss diagnostics and machine protection of all types of particle accelerators (e.g. synchrotrons and linear colliders for high-energy physics, electron accelerators for synchrotron light sources, medical accelerators for hadron therapy).  The system measures fast AC beam losses from bunched beams simultaneously with continuous DC beam losses. It is sensitive to single MIP particles and has a very high dynamic range. Bunch-by-bunch losses are resolved in real time with the ROSY® Beam Loss Application. ROSY® AX106 is designed to be integrated into any control system.
A2金刚石束线位置监测器

CIVIDEC束线装置

市场价:￥0.00

价格:￥0.00

A2 DIAMOND BEAM POSITION MONITORLocating Charged Particle BeamsThe A2 Diamond Beam Position Monitor is made to precisely measure the beam position of charged particle beams. It is used in fixed experimental beam lines at high-energy physics laboratories, in order to measure and control the beam position and intensity. The position of bunched as well as continuous charged particle beams is measured with this beam position monitoring system.  The energy loss and lateral scattering is kept to a minimum with the beam-intercepting four-quadrant pCVD detector.
A5金刚石能谱仪

CIVIDEC束线装置

市场价:￥0.00

价格:￥0.00

A5 DIAMOND SPECTROMETERThe Heavy-Ion SpectroscopeThe A5 Diamond Spectrometer is designed for high-precision spectroscopy of heavy ions. It is used for research in radiochemistry, nuclear medicine and heavy ion physics. The Diamond Spectrometer is a robust spectroscopy tool which can be used in hot environments as well as in vacuum applications. The system provides an energy resolution of 20 keV FWHM, intrinsically matched to the spectroscopic properties of diamond detectors. Energy straggling of the heavy ions is kept to a minimum by the dedicated technology.
A6金刚石相位监测器

CIVIDEC束线装置

市场价:￥0.00

价格:￥0.00

The Heavy-Ion SpectroscopeThe A5 Diamond Spectrometer is designed for high-precision spectroscopy of heavy ions. It is used for research in radiochemistry, nuclear medicine and heavy ion physics. The Diamond Spectrometer is a robust spectroscopy tool which can be used in hot environments as well as in vacuum applications. The system provides an energy resolution of 20 keV FWHM, intrinsically matched to the spectroscopic properties of diamond detectors. Energy straggling of the heavy ions is kept to a minimum by the dedicated technology.
A3 金刚石快中子监测器

CIVIDEC中子诊断

市场价:￥0.00

价格:￥0.00

The Fast-Neutron CounterThe Diamond Fast-Neutron Monitor is designed for neutron flux monitoring in fusion reactor applications. High neutron flux rates are measured with the C2-HV Broadband Amplifier, while high-precision neutron spectroscopy is performed with the Cx-L Spectroscopic Amplifier. Both amplifiers allow the installation of a 10 m long detector cable between detector and amplifier, for operation in high-radiation environments.
